ZMC4.3
Zener Diodes
Product information
| Product family | Zener Diodes Voltage stabilization |
|---|---|
| Article description |
ZMC4.3
PCN089: EOL
Zener, SOD-106, 4.3V, 0.5W, ±5% |
| Minimum order quantity | 2.500 |
| Stock | 85.000 |
| Customs Tariff Number | 85411000 |
| RoHS | compliant |
| REACH | declarable |
| Lead free | Yes |
| Halogen free | No |
Downloads & Links
Technical data
| Article number | ZMC4.3 | |
|---|---|---|
|
||
| Type | SMD | |
| Package | Quadro MicroMelf | |
| Qualification | Industrial Grade | |
| Config | Single | |
| Life Cycle | end of life | |
| ESD sensitive | No | |
| MSL | 1 | |
| Zener voltage | Vzmin | 4 V |
| Vznom | 4.3 V | |
| Vzmax | 4.6 V | |
| @ Iztest | 5 mA | |
| Power dissipation | Ptot | 0.5 W |
| @ TLoc | 25 °C | |
| Location | Ambient | |
| Power dissipation (b) | PPPM | null W |
| @ TLoc | null °C | |
| Location | null | |
| Tolerance | Voltage Tolerance | ±5% |
| Junction temperature | Tjmin | -50 °C |
| Tjmax | 175 °C | |
| Leakage current 25°C | IR | 1 µA |
| @ VR | 1 V | |
| Dynamic resistance | rzj | 75 Ω |
| @ Iz | 5 mA | |
| Junction capacitance | Cj | null pF |
| @ VR | null V | |
| Dynamic resistance (b) | rzj | null Ω |
| @ Iz | null mA | |
| Temperature coefficient | aVz | -6...-3 1E-4/°C |
| Zener current | IZmax | 109 mA |
| @ TLoc | 25 °C | |
| Location | Ambient | |
| Net weight | mnet | 0.01 g |
| Marking | Marking | Cathode band only |
| Case flammability | UL94-V0 | Yes |
| Thermal resistance junction | RTH | 300 K/W |
| Location | ambient | |
| UL recognized | UL-Recognition | null |
| Thermal resistance junction (b) | RTH | 240 K/W |
| Location | terminal | |
| Storage temperature | Tsmin | -50 °C |
| Tsmax | 175 °C | |
| Solder & Assembly | Solder & Assembly | 260°/10s |
